Technical specifications
12.1 Technical specifications
CPU 1516pro-2 PN (6ES7516-2PN00-0AB0)
122 Operating Instructions, 09/2016, A5E35873416-AA
6ES7516-2PN00-0AB0
PROFINET IO controller
Services
•
PG/OP communication
Yes
•
S7 routing
Yes
•
Isochronous mode
Yes
•
Open IE communication
Yes
•
IRT
Yes
•
MRP
Yes; as MRP redundancy manager and/or MRP
client; max. number of devices in the ring: 50
•
MRPD
Yes; requirement: IRT
•
PROFIenergy
Yes
•
Prioritized startup
Yes; max. 32 PROFINET devices
•
Number of connectable IO devices, max.
256; in total, max. 1 000 distributed I/O devices
can be connected via AS-i, PROFIBUS or
PROFINET
•
of these, IO devices with IRT, max.
64
•
Number of connectable IO devices for RT,
max.
256
•
of these, in a line topology, max.
256
•
Number of IO devices that can be ena-
bled/disabled simultaneously, max.
8; in total over all interfaces
•
Number of IO devices per tool, max.
8
•
Update times
Minimum value of update time also depends on
the communication allocation setting for
PROFINET IO, the number of IO devices and the
amount of configured user data
Update time with IRT
•
with send clock of 250 µs
250 µs to 4 ms; note: with IRT with isochronous
mode, the minimum update time of 500 µs of the
isochronous OBs is crucial
•
with send clock of 500 µs
500 µs to 8 ms
•
with send clock of 1 ms
1 ms to 16 ms
•
with send clock of 2 ms
2 ms to 32 ms
•
with send clock of 4 ms
4 ms to 64 ms
•
with IRT and "odd" send clock parameter as-
signment
Update time = set "odd" send clock (any multiple
of 125 µs: 375 µs, 625 µs to 3 875 µs)
