CPU 1516pro-2 PN (6ES7516-2PN00-0AB0)
68 Operating Instructions, 09/2016, A5E35873416-AA
This section includes information on the following topics:
● Commissioning the CPU 1516pro-2 PN on PROFINET IO
● Removing/inserting the SIMATIC memory card
● Operating modes of the CPU
● CPU memory reset
● Identification and maintenance data
Commissioning requirements
Note
Performing tests
You must ensure the safety of your plant. You therefore need to perform a complete
functional test and the necessary safety checks
before the final commissioning of a plant.
Also allow for any possible foreseeable errors in the tests. This avoids endangering persons
or equipment during operation.
SIEMENS PRONETA PC-based software tool that is provided free-of-charge, which
simplifies the commissioning of PROFINET systems by performing the following tasks:
● Topology overview that automatically scans PROFINET and displays all connected
components. This overview can be exported in the form of a device list. You have the
option of "Initializing" the components and performing other simple configuration tasks, as
well as comparing the actual configuration with a required configuration.
● IO check to quickly test the wiring of a plant and the module configuration of the
components. By reading and writing the inputs and outputs, PRONETA makes sure that
the distributed I/O devices with their sensors and actuators are correctly wired.
PRONETA can create test profile templates and store test logs to document the test
results.
● All tasks can be performed even before a CPU is integrated into the network. Moreover,
since no other engineering tools or hardware are required, PRONETA enables a fast and
convenient checking of a plant configuration at an early stage.
Additional information about PRONETA can be found here
(https://support.industry.siemens.com/cs/ww/en/view/67460624
).
