Mounting and connecting
3.3 Connecting the connection module CM CPU 2PN M12 7/8"
CPU 1516pro-2 PN (6ES7516-2PN00-0AB0)
28 Operating Instructions, 09/2016, A5E35873416-AA
Modules with PROFINET interfaces may only be operated in LANs (Local Area Network)
where all nodes are equipped with SELV / PELV power supplies or protection systems of
equal quality.
A data transfer terminal (modem, for example) is required to access the WAN (Wide Area
Network) in order to ensure compliance with this safety standard.
The CPU (including bus module) and the connection module CM CPU 2PN M12, 7/8" are
mounted on the module rack.
● Screwdriver
● Insulation stripping tool for wiring if you are assembling the cables yourself.
● Pre-fabricated cable with M12 and 7/8" connectors The patch cables are available in
different lengths.
● To produce your own cable:
– M12: PROFINET cable (4-wire, shielded) and M12 PROFINET connection plug
(d-coded)
– 7/8": 5-wire patch cable with 7/8" connectors
