Siemens Simatic ET200pro

Commissioning
7.2 Procedure for commissioning the ET 200pro distributed I/O system with CPU
CPU 1516pro-2 PN (6ES7516-2PN00-0AB0)
70 Operating Instructions, 09/2016, A5E35873416-AA
Commissioning procedure
To commission the ET 200pro distributed I/O system as an IO controller on PROFINET IO,
we recommend the following procedure:
Table 7- 1 Procedure for commissioning the ET 200pro as an IO controller on PROFINET IO
Step
Procedure
See ...
1 Mounting ET 200pro (with
CPU 1516pro-2 PN)
Section Mounting and connecting (Page 25)
Operating instructions ET 200pro Distributed I/O System
(https://support.industry.siemens.com/cs/ww/en/view/21210852)
2 Inserting the SIMATICmemory card
into IO controller
Section Inserting/replacing SIMATIC memory card (Page 73)
3 Connecting the ET 200pro
• Supply voltages
• PROFINET IO
• Sensors and actuators
Section Mounting and connecting (Page 25)
Operating instructions ET 200pro Distributed I/O System
(https://support.industry.siemens.com/cs/ww/en/view/21210852
)
4 Configuring the IO controller
1
Section Configuring the CPU (Page 35)
5 Switch on supply voltages for the
IO controller
Section Mounting and connecting (Page 25)
6 Switch on supply voltages for
IO devices
Documentation of the IO device
7 Download configuration to the
IO controller
STEP 7 online help
8
Switch IO controller to RUN mode
Section RUN mode (Page 78)
9 Check LEDs Section Interrupts, diagnostics, error messages and system events
(Page 113)
10 Test inputs and outputs The following functions are helpful: Monitoring and modifying tags, test-
ing with program status, forcing, controlling the outputs. See section
Test
functions and troubleshooting (Page 105)
1
The IO devices are configured with the IO controller.
