Siemens Simatic ET200pro

Commissioning
7.2 Procedure for commissioning the ET 200pro distributed I/O system with CPU
CPU 1516pro-2 PN (6ES7516-2PN00-0AB0)
72 Operating Instructions, 09/2016, A5E35873416-AA
Commissioning procedure
To commission the ET 200pro distributed I/O system as an I-device on PROFINET IO, we
recommend the following procedure:
Table 7- 2 Procedure for commissioning the ET 200pro as an I-device on PROFINET IO
Step
Procedure
See ...
1 Mounting ET 200pro (with
CPU 1516pro-2 PN)
Section Mounting and connecting (Page 25)
Operating instructions ET 200pro Distributed I/O System
(https://support.industry.siemens.com/cs/ww/en/view/21210852)
2 Inserting the SIMATIC memory
card into the I-device
Section Inserting/replacing SIMATIC memory card (Page 73)
3 Connecting the ET 200pro
• Supply voltages
• PROFINET IO
• Sensors and actuators
Operating instructions ET 200pro Distributed I/O System
(https://support.industry.siemens.com/cs/ww/en/view/21210852
)
4 Configuring the I-device Section Configuring the CPU (Page 35)
5 Switch on supply voltages for the
IO controller
Documentation of the IO controller
6 Switch on supply voltages for I-
device and IO devices
Section Mounting and connecting (Page 25) and documentation of the IO de-
vices
7 Download configuration to the
I-device
STEP 7 online help
8 Switch IO controller and I-device
to RUN mode
Documentation of the IO controller and section RUN mode (Page 78)
9
Check LEDs
Section Interrupts, diagnostics, error messages and system events (Page 113)
10 Test inputs and outputs The following functions are helpful: Monitoring and modifying tags, testing with
program status, forcing, controlling the outputs. See section
Test functions and
troubleshooting (Page 105)
