Commissioning
7.7 Identification and maintenance data
CPU 1516pro-2 PN (6ES7516-2PN00-0AB0)
88 Operating Instructions, 09/2016, A5E35873416-AA
Procedure for reading the I&M data via STEP 7
Requirements: An online connection to the CPU must exist.
To read the I&M data via STEP 7, follow these steps:
1. Select the CPU 1516pro-2 PN in the project tree and go to "Online & diagnostics".
2. Select the "General" area in the "Diagnostics" folder.
Procedure for entering the maintenance data via STEP 7
STEP 7 assigns a default module name. You can enter the following information:
● Plant designation (I&M1)
● Location identifier (I&M1)
● Installation date (I&M2)
● Additional information (I&M3)
To enter maintenance data via STEP 7, follow these steps:
1. In the device view of the hardware network editor of STEP 7, select the CPU, for
example.
2. In the properties under "General", select the "Identification & Maintenance" area and
enter the data.
During the loading of the hardware configuration, the I&M data is also loaded.
Procedure for reading out the I&M data via the Web server
The procedure is described in detail in the Web server
(http://support.automation.siemens.com/WW/view/en/59193560
) Function Manual.
