Siemens Simatic ET200pro

Commissioning
7.7 Identification and maintenance data
CPU 1516pro-2 PN (6ES7516-2PN00-0AB0)
90 Operating Instructions, 09/2016, A5E35873416-AA
Table 7- 6 Data record structure for I&M identification data
Identification data
Access
Default
Explanation
Identification data 0: (data record index AFF0 hex)
VendorIDHigh Read (1 byte) 00
H
This is where the name of the manufac-
turer is stored (42
D
= SIEMENS AG).
VendorIDLow
Read (1 byte)
2A
H
Order_ID Read (20 bytes) 6ES71516-2PN00-0AB0 Article number of module (e.g. CPU)
IM_SERIAL_NUMBER
Read (16 bytes)
-
Serial number (device-specific)
IM_HARDWARE_REVISION
Read (2 bytes)
1
Corresponding HW version
IM_SOFTWARE_REVISION
Read
Firmware version
Provides information about the firmware
version of the module
• SWRevisionPrefix
(1 byte) V
• IM_SWRevision_Functional_
Enhancement
(1 byte) 00 - FF
H
• IM_SWRevision_Bug_Fix
(1 byte) 00 - FF
H
• IM_SWRevision_Internal_
Change
(1 byte) 00 - FF
H
IM_REVISION_COUNTER Read (2 bytes) 0000
H
Provides information about parameter
changes on the module
(not used)
IM_PROFILE_ID
Read (2 bytes)
0000
H
Generic Device
IM_PROFILE_SPECIFIC_TYPE Read (2 bytes)
0001
H
CPU
0003
H
Modules
IM_VERSION
Read
0101
H
Provides information on the version of
the identification data
(0101
H
= Version 1.1)
• IM_Version_Major
(1 byte)
• IM_Version_Minor
(1 byte)
IM_SUPPORTED Read (2 bytes) 000E
H
Provides information about the available
identification data (I&M1 to I&M3)
Maintenance data 1: (data record index AFF1 hex)
IM_TAG_FUNCTION Read/write (32
bytes)
- Enter a module identifier here that is
unique plant-wide.
IM_TAG_LOCATION Read/write (22
bytes)
- Enter the installation location of the mod-
ule here.
Maintenance data 2: (data record index AFF2 hex)
IM_DATE Read/write (16
bytes)
YYYY-MM-DD HH:MM Enter the installation date of the module
here.
Maintenance data 3: (data record index AFF3 hex)
IM_DESCRIPTOR Read/write (54
bytes)
- Enter a comment describing the module.
