SIMATIC memory card
8.1 SIMATIC memory card - overview
CPU 1516pro-2 PN (6ES7516-2PN00-0AB0)
Operating Instructions, 09/2016, A5E35873416-AA
93
Labeling of the SIMATIC memory card
Slider for enabling write protection:
• Slider up: not write-protected
• Slider down: write-protected
Figure 8-1 Labeling of the SIMATIC memory card
Folders and files on the SIMATIC memory card
The following folders and files can be found on the SIMATIC memory card:
Table 8- 1 Folder structure
Firmware update files for CPU and modules
SIMATIC.S7S User program, i.e. all blocks (OBs, FCs, FBs, DBs) and system
blocks, project data of the CPU
