Parameterizing the Mobile Panel
5.15 Functions for service and commissioning
Mobile Panels 2nd Generation
Operating Instructions, 09/2018, A5E33876626-AC
155
8. Press the "Load" button to transfer the project data with the selected options to the HMI
device.
The new project starts on the HMI device after the load operation.
The "Automatic backup" function is available on all Mobile Panels 2nd Generation with the
exception of the KTP400F Mobile.
When you activate the "Automatic backup" function, the data of the HMI device is
automatically backed up to the SD memory card during operation in form of a backup
including firmware. Backup is synchronized.
Note
The memory card can be used either as data memory card or system memory card.
When you activate the "Automatic backup" function, the SD memory card of the Mobile
Panel is used as system memory card
and can no longer be used as data memory card.
Use only a SIMATIC HMI Memory Card as the system memory card.
Only the SIMATIC
HMI Memory Card ≥ 2 GB may be used as a system memory card. All
other memory cards are not recognized as system memory card by the HMI device.
System memory card in a device of a different type
If you use the system memory card of an HMI device in an HMI device of a different type, an
error message is displayed.
For service purposes, use a system memory card only in HMI devices of the same type.
Do not remove the system memory card for "automatic backup" during operation
If the "Automatic backup" function is activated, the system memory card may only be
removed when the HMI device is switched off.
Automatic backup and updating the operating system
When you wa
nt to update the operating system of the HMI device and have activated the
"Automatic backup" function, leave the memory card in the HMI device before and after the
entire update.
The "Automatic Backup" function is deactivated in the delivery state of the device.
