Siemens SIMATIC HMI KTP400F Mobile - F_Fb_Ktp_Rng

Technical specifications
11.14 Mobile Panel 2nd Generation F-FBs
Mobile Panels 2nd Generation
Operating Instructions, 09/2018, A5E33876626-AC
263
11.14.3
F_FB_KTP_RNG
Inputs
Parameter
Data type
Description
Interconnection
ID Word The connection box is uniquely identified by
the ID set on the connection box. The ID
must be unique throughout the plant and
must match the value of this parameter. The
value has the following meaning:
0 or > 254: Invalid box ID, emergency stop
and acknowledgment button are disabled.
1...254: Valid box ID, emergency stop and
acknowledgment button enabled depending
on the mode of the HMI device.
---
E_STOP_EXT Bool External information on the state of the
emergency stop button of another
F_FB_KTP_RNG with cascading.
ENABLE_EXT Bool External information on the state of the
acknowledgement button of another
F_FB_KTP_RNG with cascading.
ACTIVATE_ENABLE Bool This input allows the acknowledgement
button to be enabled and disabled.
MP1_E_STOP Word Information from the F_FB_KTP_Mobile on
the state of the emergency stop button of
HMI device 1
MP1_ENABLE Word Information from the F_FB_KTP_Mobile on
the state of the acknowledgment button of
HMI device 1
MP2_E_STOP Word Information from the F_FB_KTP_Mobile on
the state of the emergency stop button of
HMI device 2
MP2_ENABLE Word Information from the F_FB_KTP_Mobile on
the state of the acknowledgment button of
HMI device 2
