1.10 Mobile Panel and connection box compatibility
Mobile Panels 2nd Generation
Operating Instructions, 09/2018, A5E33876626-AC
29
F-systems
The table below shows the F-systems that can be configured or installed for a given
connection box. Requirement is that you are using a fail-safe Mobile Panel.
Connection box
PROFIsafe-
based F-system
Hardwired F-system, no
emergency stop/stop bypass
Hardwired F-system with
emergency stop/stop bypass
compact
Yes
Yes
No
standard Yes Yes No
advanced
Yes
No
Yes
Safety-related
operating mode
E-stop button
evaluated by
PROFIsafe
Stop button evaluated by
safety relay
Stop button evaluated by
safety relay
E-stop button evaluated by
safety relay
E-stop button evaluated by
safety relay
1.10
Mobile Panel and connection box compatibility
This section addresses the following compatibility:
● Ccompatibility of Mobile Panels 2nd Generation to connection box PN Basic and PN Plus
● Ccompatibility of Mobile Panels 1st Generation to connection boxes compact, standard
und advanced
The Mobile Panels 2nd Generation are not compatible with the connection box DP Basic and
connection box DP Plus.
Ccompatibility of Mobile Panels 2nd Generation – connection box PN Basic and PN Plus
The 2nd Generation Mobile Panels are compatible with the following connection boxes:
● Connection box PN Basic, article number 6AV6671-5AE01-0AX0
● Connection box PN Plus, article number 6AV6671-5AE11-0AX0
Restrictions:
● Only one hardwired F-system with a stop function and enabling function is permitted.
● PROFINET communication is possible with the connection boxes PN Basic and PN Plus,
a PROFIsafe -based F-system is not feasible.
● Note the reduced maximum permissible amperage for the acknowledgment button circuit
in the technical specifications, section "Connection boxes (Page 236)".
