Technical specifications
11.8 Technical specifications
Mobile Panels 2nd Generation
238 Operating Instructions, 09/2018, A5E33876626-AC
● Connection boxes standard and advanced: Any screw glands not used are fitted with a
cover.
Device side
Explanation
All-round
• IP65 according to IEC 60529
• Type 4X/Type 12 (indoor use only) to UL50
Applies if indicated on the nameplate
11.8.4
Power consumption specifications
The connection box and Mobile Panel must be taken into consideration when calculating the
power consumption. The tables below show typical values for the power consumption.
Note
The actual power consumption may vary depending on the conf
iguration and the load at the
interfaces of the Mobile Panel deviating from the specified values. The following factors
affect the power consumption, for example:
•
The display brightness set on the Mobile Panel
•
The load on the USB interface of the Mobile Panel
•
The length of the connecting cable
Connection box
Power consumption
1
Connection box compact
0.5 W
Connection box standard
2.4 W
Connection box advanced
2.8 W
1
The power loss generally corresponds to the specified value for power consumption.
Mobile Panel
Power consumption
1
KTP400F Mobile
6 W
KTP700 Mobile
7 W
KTP700F Mobile
8 W
KTP900 Mobile
9 W
KTP900F Mobile
10 W
1
The power loss generally corresponds to the specified value for power consumption.
The total power consumption for the HMI device is calculated as follows:
Total power consumption = power consumption connection box + power consumption Mobile
Panel
