Siemens SIMATIC HMI KTP900 Basic User Manual

Technical specifications
8.7 Technical specifications
Basic Panels 2nd Generation
112 Operating Instructions, 10/2016, A5E33293231-AB
Interfaces
KTP900 Basic
KTP1200 Basic
KTP1200 Basic DP
1 x RS 422/RS 485
-
Max. 12 Mbps
1 x Ethernet RJ45 10/100 Mbps -
USB 2.0
Yes
Supply voltage
KTP900 Basic
KTP1200 Basic
KTP1200 Basic DP
Rated voltage +24 V DC
Permitted voltage range
19.2 .. 28.8 V (–20%, +20%)
Transients, maximum permitted 35 V (500 ms)
Time between two transients, minimum
50 s
Current
consumption
Typical
Approx. 230 mA
Approx. 510 mA
Approx. 550 mA
Constant current, maximum
Approx. 440 mA
Approx. 650 mA
Approx. 800 mA
Inrush current I
2
t
Approx. 0.2 A
2
s
Fuse, internal
Electronic
Miscellaneous
KTP900 Basic
KTP1200 Basic
KTP1200 Basic DP
Buffered real-time clock
1
,
can be synchronized
Yes
Acoustic feedback
Yes
1
Typical buffer time: 3 weeks

Siemens SIMATIC HMI KTP900 Basic Specifications

General

Display Size	9 inches
Display Type	TFT
Resolution	800 x 480 pixels
Touchscreen	Yes
Interface	PROFINET
Power Supply	24 V DC
Operating System	Windows CE
USB Port	1 x USB 2.0
Ambient Temperature (Operation)	0 to 50 °C
Ambient Temperature (Storage)	-20 to 60 °C
Relative Humidity	10% to 90% (non-condensing)
Protection Rating	IP65 (front)
Memory	12 MB
Communication Ports	Ethernet (RJ45)
Number of Colors	65536
