Siemens SIMATIC HMI KTP900 Basic User Manual

Technical specifications
8.7 Technical specifications
Basic Panels 2nd Generation
Operating Instructions, 10/2016, A5E33293231-AB
111
8.7.3
KTP900 Basic, KTP1200 Basic and KTP1200 Basic DP
HMI device
KTP900 Basic
KTP1200 Basic
KTP1200 Basic DP
Weight without packaging
Approx. 1130 g
Approx. 1710 g
Approx. 1710 g
Display
KTP900 Basic
KTP1200 Basic
KTP1200 Basic DP
Type
LCD TFT
Display area, active
198.0 mm x 111.7 mm (9")
261.1 mm x 163.2 mm (12")
Resolution, pixels 800 x 480 1280 x 800
Colors, displayable
16-bit (65536 colors)
Brightness control
Yes
Pixel error class in accordance with
EN ISO 9241-307
II
Backlighting
Half Brightness Life Time (MTBF
1
)
LED
20,000 h
1
MTBF: Operating hours after which the maximum brightness is reduced by half compared to the original value. MTBF is
increased by using the integrated dimming function, for example time-driven dimming using the screen saver or central
dimming by the controller.
Input device
KTP900 Basic
KTP1200 Basic
KTP1200 Basic DP
Type
Touch screen, analog resistive
Function keys
8
10
Labeling strips
Yes
Memory
KTP900 Basic
KTP1200 Basic
KTP1200 Basic DP
Data memory
256 MB
Program memory
512 MB

Siemens SIMATIC HMI KTP900 Basic Specifications

General

Display Size	9 inches
Display Type	TFT
Resolution	800 x 480 pixels
Touchscreen	Yes
Interface	PROFINET
Power Supply	24 V DC
Operating System	Windows CE
USB Port	1 x USB 2.0
Ambient Temperature (Operation)	0 to 50 °C
Ambient Temperature (Storage)	-20 to 60 °C
Relative Humidity	10% to 90% (non-condensing)
Protection Rating	IP65 (front)
Memory	12 MB
Communication Ports	Ethernet (RJ45)
Number of Colors	65536
