Preface
Basic Panels 2nd Generation
Operating Instructions, 10/2016, A5E33293231-AB
5
Illustrations and text highlighting
This manual contains figures of the described devices. The figures may deviate from the
supplied device in certain details.
The following graphical highlighting facilitates reading these operating instructions:
Graphical highlighting
Description
If the instructions involve several
tasks, the individual tasks are
highlighted by a red number circle.
A light blue highlight indicates
components and tools that are
required in the course of a task.
KTP700 Basic is sometimes shown
in the figures as a representation of
all Basic Panels.
The following text highlighting facilitates reading these operating instructions:
Text highlighting
Scope
"Add screen"
• Terms that appear in the user interface, for example, dialog names, tabs,
buttons, menu commands
• Input values, for example, limits, tag values
• Path information
"File > Edit" Operational sequences, for example, menu commands, shortcut menu
commands
<F1>
Keyboard operation

Siemens SIMATIC HMI KTP900 Basic Specifications

General

Display Size	9 inches
Display Type	TFT
Resolution	800 x 480 pixels
Touchscreen	Yes
Interface	PROFINET
Power Supply	24 V DC
Operating System	Windows CE
USB Port	1 x USB 2.0
Ambient Temperature (Operation)	0 to 50 °C
Ambient Temperature (Storage)	-20 to 60 °C
Relative Humidity	10% to 90% (non-condensing)
Protection Rating	IP65 (front)
Memory	12 MB
Communication Ports	Ethernet (RJ45)
Number of Colors	65536
