3.2 Mounting the device
SIMATIC IPC127E
Operating Instructions, 01/2019, A5E44296915-AA
25
Fasten securely
Insufficient load carrying capacity
If the mounting surface for wall and vertical mounting does not have sufficient load carrying
capability, the device may fall down and be damaged.
Ensure that the mounting surface on the wall can bear four times the total weight of the
device, including fixing elements.
Incorrect fixing elements
If you use anchors and screws other than those specified below for wall and vertical
mounting, safe mounting is not guaranteed. The device can fall and may be damaged.
Use only the anchors and screws specified in the following table.
Concrete Select according to the
specification of the
mounting elements used
• Anchor, ∅ 6 mm, 40 mm long
• Screw, ∅ 4-5 mm, 40 mm long
Plasterboard,
Toggle plug, ∅ 12 mm, 50 mm long
Metal,
min. 2 mm thick
• Screw M4 × 15
• M4 nut
To Next Page
