SIMATIC IPC127E
Operating Instructions, 01/2019, A5E44296915-AA
75
Hardware description
10
10.1 Technical features of the motherboard
Component /
port
Description
Parameters
Chipset
integrated in CPU
BIOS
Core, Video, ACPI
CPU
Intel Atom
Memory
LPDDR4
2 GB, 4 GB
Graphics Integrated graphics up to 512 MB graphics memory taken
dynamically from RAM
10.2 External interfaces
10.2.1 Overview of interfaces
Interface
Posi-
tion
Description (Basic / Extended device)
USB Exter-
nal
2 / 4 USB channels 2 / 4 × USB 3.0
Ethernet Exter-
nal
2 x RJ45 / 3 x RJ45 10/100/1000 Mbps
DisplayPort Exter-
nal
DP
10.2.2 USB 3.0 port
Pin
Short name
Meaning
Input / output
1
VBUS
+ 5 V (fused)
Output
2
D-
Data channel USB2
Input / output
3
D+
Data channel USB2
Input / output
4
GND
Ground
–
5
RX-
Data channel USB3
Input
6
RX+
Data channel USB3
Input
7
GND
Ground
–
8
TX-
Data channel USB3
Output
9
TX+
Data channel USB3
Output
