Mounting and connecting the device
3.2 Mounting the device
SIMATIC IPC127E
24 Operating Instructions, 01/2019, A5E44296915-AA
3.2 Mounting the device
3.2.1 Mounting instructions
Note the following:
The device is approved for operation in closed rooms only.
For installation in a cabinet, observe the "Directives for interference-free installation of
programmable logic controllers
(http://support.automation.siemens.com/WW/view/de/1064706)" as well as the relevant
DIN/VDE provisions and the applicable country-specific regulations.
Possible mounting types of the device:
Mounting on a standard rail
Wall mounting
Upright mounting
Vertical mounting standard rail
The mounting types are described in the following sections using the standard device as an
example.
Position of the interfaces
The position of the interface side is determined by the mounting of the mounting bracket.
For mounting on a standard rail, the interface side of the device can point either up or down
and to the right or to the left.
In the case of wall mounting, the interface side of the device can point up, down, to the left or
to the right.
For vertical mounting, the interface side of the device can point either to the front (with Basic
device only), up or down (Extended device).
