Technical specifications
6.1 General technical specifications
SIMATIC IPC127E
54 Operating Instructions, 01/2019, A5E44296915-AA
Electromagnetic compatibility
Immunity with regard to conducted
interference on the supply lines
± 2 kV according to IEC 61000-4-4; burst
± 0.5 kV according to IEC 61000-4-5; surge symmetrical
± 1 kV according to IEC 61000-4-5; surge asymmetrical
Noise immunity on signal lines ± 1 kV to IEC 61000-4-4; Burst; Length < 3 m
± 2 kV in accordance with IEC 61000-4-4; Burst; length > 3 m
± 2 kV in accordance with IEC 61000-4-5; Surge; length > 30 m
Immunity to discharges of static
electricity
± 6 kV contact discharge in accordance with IEC 61000-4-2
± 8 kV air discharge in accordance with IEC 61000-4-2
Immunity to RF interference 10 V/m, 80 … 2 GHz,
80% AM according to IEC 61000-4-3
3 V/m, 2 … 6 GHz, 80% AM according to IEC 61000-4-3
10 V, 10 KHz … 80 MHz, 80% AM according to IEC 61000-4-6
Magnetic field 100 A/m, RMS value 50/60 Hz in accordance with IEC 61000-
4-8
Main circuit board
Processor / main memory
• Intel Atom E3930, 2 cores/2 threads, 2 GB RAM
• Intel Atom E3940, 4 cores/4 threads, 4 GB RAM
• Intel Atom E3930, 2 cores/2 threads, 2 GB RAM; TPM
• Intel Atom E3940, 4 cores/4 threads, 4 GB RAM; TPM
• LPDDR4 memory
Drive, memory medium
Solid State Drive
• 32 GB SSD
• 64 GB SSD
• 128 GB SSD
Floppy and CD-ROM drive
External, can be connected via USB port
1
USB stick
External, can be connected via USB port
1
Only to device USB port, not via USB hub
Graphics
Graphics controller
Integrated Graphic Controller
Graphics memory
Up to 512 MB, shared memory
Resolution, graphics memory
• DisplayPort resolution:
640 × 480 pixels to 4096 × 2160 pixels
• Up to 512 MB graphics memory is taken from main
memory, UMA, dynamic
