6.3 SIMATIC RF620A
SIMATIC RF600
226 System Manual, 11/2018, J31069-D0171-U001-A21-7618
6.3.2 Ordering data
Table 6- 10 Ordering data RF620A
Product
Article number
SIMATIC RF620A (ETSI)
6GT2812-1EA00
SIMATIC RF620A (FCC) 6GT2812-1EA01
Table 6- 11 Ordering data accessories
Product
Article number
Connecting cable between
reader and antenna
1 m (cable loss 0.5 dB)
6GT2815-0BH10
3 m (cable loss 1.0 dB) 6GT2815-0BH30
5 m, suitable for drag chains
(cable loss 1.5 dB)
6GT2815-2BH50
10 m (cable loss 2.0 dB)
6GT2815-1BN10
10 m (cable loss 4.0 dB)
6GT2815-0BN10
15 m, suitable for drag chains
(cable loss 4.0 dB)
6GT2815-2BN15
20 m (cable loss 4.0 dB)
6GT2815-0BN20
40 m (cable loss 5.0 dB)
6GT2815-0BN40
6.3.3 Installation
Two holes for M5 screws are provided for mounting the antenna. The antenna is suitable for
mounting on metallic and non-metallic surfaces.
Note
Achieving optimum wave propagation
To achieve
optimum wave propagation,
the antenna should not be surrounded by conducting
objects. The area between antenna and transponder should also allow wave propagation
without interference.
Note
Antenna gain depends on the mounting surface
Note that the
antenna gain depends on the material of the mounting surface. If the antenna
is mounted on a metallic surface, the antenna gain is
-5 dBi. If the antenna is mounted on a
non
-metallic surface, the antenna gain is -10 dBi.
