Antennas
6.4 SIMATIC RF640A
SIMATIC RF600
System Manual, 11/2018, J31069-D0171-U001-A21-7618
249
Limitations in Japan
Note
Limitation of the radiated power (ARIB STD-T107)
RF600 systems that are put
into operation in Japan must not exceed the following radiated
with an RF640A antenna:
500 mW EIRP (or 27 dBm EIRP)
6.4.5.2 Setting RF640A parameters for RF680R/RF685R
Depending on the country or region in which the antenna is being operated, it is subject to
regional limitations with respect to the radiated power.
Limitations in the EU, EFTA, or Turkey
Note
Limitation of the radiated power according to EN 302 208 V1.4.1 (ETSI)
RF600 systems that are put into operation in the EU, EFTA or Turkey must no
t exceed the
following radiated power with an RF640A
antenna:
2000 mW ERP (or 33 dBm ERP)
Converted into EIRP: 3250 mW EIRP (or 35 dBm EIRP)
Make the following settings to ensure that the maximum permitted radiated power of the
antenna is not exceeded:
● Antenna gain: 4 dBi (or 7 dBiC)
● Radiated power: ≤ 2000 mW ERP (or 33 dBm ERP)
Converted into EIRP: ≤ 3250 mW EIRP (or 35 dBm EIRP)
● Use of cable loss associated with the antenna cable.
