Transponder
7.3 SIMATIC RF640L Smartlabel
SIMATIC RF600
System Manual, 11/2018, J31069-D0171-U001-A21-7618
355
7.2.5 Certificates and approvals
Conformity with the RED directive 2014/53/EU
Conformity with the RoHS directive 2011/65/EU
Federal Communications
Passive labels and transponders comply with the valid regulations;
certification is not required.
7.3 SIMATIC RF640L Smartlabel
7.3.1 Features
The SIMATIC RF640L Smartlabel is a passive and maintenance-free data carrier. It operates
based on UHF Class 1 Gen 2 technology and is used to save the "Electronic Product Code"
(EPC) up to 448 bits. The transponder also has 2048 bits of user memory.
The SIMATIC RF640L is designed for direct mounting on metal surfaces.
Smartlabel SIMATIC RF640L
Area of application
Industrial plant management,
RF identification of tools, containers and metallic
Frequency range
• ETSI: 865 to 868 MHz
• FCC: 902 to 928 MHz
According to ISO 18000-63
Memory
• EPC: 8 ... 60 bytes / 64 ... 480 bits
1)
• User memory: 16 ... 64 bytes / 128 ... 512 bits
1)
2)
Mounting Self-adhesive
Designed for mounting directly on metal
The EPC memory has a default size of 96 bits. When necessary, the EPC memory size can be expanded to 480 bits in
steps of 16 bits at the cost of the user memory.
2)
Depending on the environment, the employed reader/the antennas and the set power
