Transponder
7.6 SIMATIC RF610T
SIMATIC RF600
372 System Manual, 11/2018, J31069-D0171-U001-A21-7618
7.6.4 Dimension drawing
Figure 7-14 Dimensional drawing of SIMATIC RF610T
All dimensions in mm
7.6.5 Certificates and approvals
Conformity with the RED directive 2014/53/EU
Conformity with the RoHS directive 2011/65/EU
Federal Communications
Passive labels and transponders comply with the valid regulations;
certification is not required.
This product is UL-certified for the USA and Canada.
It meets the following safety standard(s):
• UL508 - Industrial Control Equipment
• CSA C22.2 No. 142 - Process Control Equipment
• UL Report E 120869
