Transponder
7.9 SIMATIC RF622T
SIMATIC RF600
388 System Manual, 11/2018, J31069-D0171-U001-A21-7618
7.9 SIMATIC RF622T
7.9.1 Features
The SIMATIC RF622T is a passive and maintenance-free data carrier. It operates on the
basis of the UHF Class 1 Gen 2 technology and has a fast FRAM user memory of 3,424
bytes.
The SIMATIC RF622T achieves a read range of up to 3 m on a non-metallic surface and 1 m
on metallic containers with a spacer. This means that the RF622T allows numerous uses in
the widest range of applications.
Area of application Industrial plant management,
RFID identification of tools and containers.
According to ISO 18000-63
Memory
• EPC: 496 bits
• User memory: 3424 bytes
Read range
• Max. 3 m on non-metallic surface
1)
• Max. 1 m on metal with spacer
1)
Mounting 2 x M4 screws
Labeling area â‘
Possible types of labeling:
• Barcode
• Data matrix code
• Labeling in plain text
It can be labeled with an adhesive label or by
1)
Depending on the environment, the employed reader/the antennas and the set power
7.9.2 Ordering data
Table 7- 32 Ordering data RF622T
Spacer for SIMATIC RF622T
