Transponder
7.1 Overview
SIMATIC RF600
System Manual, 11/2018, J31069-D0171-U001-A21-7618
347
7.1.7 Storage and transportation roll goods
Notes on storage and transportation of rolls
Note the following information on the storage and transportation of rolls:
• Protect the transponders from direct sunlight and heat (e.g. heating appliances).
• Prior to use, store the label rolls in the polyethylene bag or the shrink film of the original
packaging.
• Store the label rolls in a cool and dry location.
Ideal conditions: 18 °C ±5 °C, 40-60 % humidity
• Stack several label rolls lying flat and centered one above the other.
• Avoid external pressure (e.g. a narrow box).
Figure 7-6 Storage of transponders
