6.7 SIMATIC RF660A
SIMATIC RF600
300 System Manual, 11/2018, J31069-D0171-U001-A21-7618
6.7.2 Ordering data
Table 6- 35 Ordering data RF660A
Product
Article number
SIMATIC RF660A (ETSI)
6GT2812-0AA00
SIMATIC RF660A (FCC) 6GT2812-0AA01
Table 6- 36 Ordering data accessories
Product
Article number
Connecting cable between
reader and antenna
1 m (cable loss 0.5 dB)
6GT2815-0BH10
3 m (cable loss 1.0 dB) 6GT2815-0BH30
5 m, suitable for drag chains
(cable loss 1.5 dB)
6GT2815-2BH50
10 m (cable loss 2.0 dB)
6GT2815-1BN10
10 m (cable loss 4.0 dB)
6GT2815-0BN10
15 m, suitable for drag chains
(cable loss 4.0 dB)
6GT2815-2BN15
20 m (cable loss 4.0 dB)
6GT2815-0BN20
40 m (cable loss 5.0 dB)
6GT2815-0BN40
SIMATIC antenna holder for RF600 devices
6GT2890-2AB10
Antenna mounting kit
6GT2890-0AA00
6.7.3 Installation
Mounting system
A standardized VESA 100 mounting system is provided to mount the antenna. The mounting
system consists of four fixing holes for M4 screws at intervals of 100 mm. The antenna is
suitable for mounting on metallic and non-metallic surfaces.
Note
Achieving optimum wave propagation
To achieve optimum wave propagation, the antenna should not be surrounded by conducting
objects. The area between antenna and transpon
der should also allow wave propagation
without interference.
Antenna holders
The Siemens antenna holders allow for fine adjustment of the antenna field by setting the
solid angle.
