Siemens SIMATIC RF685R - Dimension Drawing; Approvals & Certificates

Antennas
6.8 SIMATIC RF680A
SIMATIC RF600
330 System Manual, 11/2018, J31069-D0171-U001-A21-7618
6.8.8 Dimension drawing
Figure 6-63 Dimension drawing RF680A
All dimensions in mm
6.8.9 Approvals & certificates
Table 6- 47 6GT2812-2GB08
Labeling
Description
Conformity with the RED directive 2014/53/EU
Conformity with the RoHS directive 2011/65/EU
