Transponder
7.13 SIMATIC RF645T
SIMATIC RF600
System Manual, 11/2018, J31069-D0171-U001-A21-7618
423
Mechanical specifications
Permitted ambient conditions
• In operation, during write/read access
• -40 ... +85 °C
• In operation, outside write/read access • -40 ... +85 °C
• During transportation and storage • -40 ... +85 °C
Distance from metal 0 mm
Designed for mounting directly on metal
Shock according to DIN EN 60721-3-7
2)
500 m/s
2
Vibrations according to EN 60068-2-6
2)
2
Resistance to mechanical stress
Design, dimensions and weight
52 (±0.5) × 36 (±0.5) × 12.5 mm
Type of mounting
• Glued
• Mounting cover (M4)
• Retaining bracket (M5)
Depending on the environment
2)
The values for shock and vibration are maximum values and must not be applied continuously.
