Siemens Simatic S7-1500 CPU 1512C-1 PN User Manual

Wiring
4.3 Terminal and block diagrams
CPU 1512C-1 PN (6ES7512-1CK01-0AB0)
Manual, 12/2017, A5E40898741-AA
101
The figure below shows the current flow with correct wiring when a potential difference exits
between the grounding points.
①
Grounding point functional earth 1 (FE 1)
②
Grounding point functional earth 2 (FE 2)
Figure 4-21 Potential difference using the digital on-board I/O X11 as an example
Equipotential bonding occurs via terminals 30 and 40. When a potential difference exists
between the grounding points FE1 and FE2, the compensating current flows via terminals 30
and 40.
WARNING
Current flow with faulty wiring
In the event of a potential difference, the current can be very high, depending on the
potential conditions, and lead to the destruction of the module.

Siemens Simatic S7-1500 CPU 1512C-1 PN Specifications

General

Integrated Interfaces	PROFINET
Data Memory	1 MB
Number of Signal Boards	1
Firmware Version	V2.8
Rated Value (DC)	24 V
Number of PROFINET Ports	2
Number of PROFINET Ports with Switch	2
Integrated Web Server	Yes
Number of Digital Inputs	16
Number of Digital Outputs	16
Number of Analog Outputs	2
Number of High-speed Counters	6
Program Memory	300 KB
Number of Signal Modules	32
Engineering with	STEP 7 Professional V13
Interface Type	Ethernet
Data Storage	Yes
Operating Temperature	0 to 60 °C
Dimensions	147 mm x 129 mm
