Siemens Simatic S7-1500 CPU 1512C-1 PN User Manual

Technical specifications
CPU 1512C-1 PN (6ES7512-1CK01-0AB0)
Manual, 12/2017, A5E40898741-AA
143
Article number
6ES7512-1CK01-0AB0
FC
• Number range
0 ... 65 535
• Size, max.
250 kbyte
OB
• Size, max.
250 kbyte
• Number of free cycle OBs
100
• Number of time alarm OBs
20
• Number of delay alarm OBs
20
• Number of cyclic interrupt OBs
20; With minimum OB 3x cycle of 500 µs
• Number of process alarm OBs
50
• Number of DPV1 alarm OBs
3
• Number of isochronous mode OBs
1
• Number of technology synchronous alarm
OBs
2
• Number of startup OBs
100
• Number of asynchronous error OBs
4
• Number of synchronous error OBs
2
• Number of diagnostic alarm OBs
1
Nesting depth
• per priority class
24
Counters, timers and their retentivity
S7 counter
• Number
2 048
Retentivity
– adjustable
Yes
IEC counter
• Number
Any (only limited by the main memory)
Retentivity
– adjustable
Yes
S7 times
• Number
2 048
Retentivity
– adjustable
Yes
IEC timer
• Number
Any (only limited by the main memory)
Retentivity
– adjustable
Yes

Siemens Simatic S7-1500 CPU 1512C-1 PN Specifications

General

Integrated Interfaces	PROFINET
Data Memory	1 MB
Number of Signal Boards	1
Firmware Version	V2.8
Rated Value (DC)	24 V
Number of PROFINET Ports	2
Number of PROFINET Ports with Switch	2
Integrated Web Server	Yes
Number of Digital Inputs	16
Number of Digital Outputs	16
Number of Analog Outputs	2
Number of High-speed Counters	6
Program Memory	300 KB
Number of Signal Modules	32
Engineering with	STEP 7 Professional V13
Interface Type	Ethernet
Data Storage	Yes
Operating Temperature	0 to 60 °C
Dimensions	147 mm x 129 mm
