Siemens Simatic S7-1500 CPU 1512C-1 PN User Manual

Technical specifications
CPU 1512C-1 PN (6ES7512-1CK01-0AB0)
144 Manual, 12/2017, A5E40898741-AA
Article number
6ES7512-1CK01-0AB0
Data areas and their retentivity
Retentive data area (incl. timers, counters,
flags), max.
128 kbyte; In total; available retentive memory for
bit memories, timers, counters, DBs, and tech-
nology data (axes): 88 KB
Extended retentive data area (incl. timers,
counters, flags), max.
1 Mbyte; When using PS 60W 24/48/60V DC HF
Flag
• Number, max.
16 kbyte
• Number of clock memories
8; 8 clock memory bits, grouped into one clock
memory byte
Data blocks
• Retentivity adjustable
Yes
• Retentivity preset
No
Local data
• per priority class, max.
64 kbyte; max. 16 KB per block
Address area
Number of IO modules
2 048; max. number of modules / submodules
I/O address area
• Inputs
32 kbyte; All inputs are in the process image
• Outputs
32 kbyte; All outputs are in the process image
per integrated IO subsystem
– Inputs (volume)
8 kbyte
– Outputs (volume)
8 kbyte
per CM/CP
– Inputs (volume)
8 kbyte
– Outputs (volume)
8 kbyte
Subprocess images
• Number of subprocess images, max.
32
Hardware configuration
Number of distributed IO systems 32; A distributed I/O system is characterized not
only by the integration of distributed I/O via
PROFINET or PROFIBUS communication mod-
ules, but also by the connection of I/O via AS-i
master modules or links (e.g. IE/PB-Link)
Number of DP masters
• Via CM
6; A maximum of 6 CMs/CPs (PROFIBUS,
PROFINET, Ethernet) can be inserted in total
Number of IO Controllers
• integrated
1
• Via CM
6; A maximum of 6 CMs/CPs (PROFIBUS,
PROFINET, Ethernet) can be inserted in total

Siemens Simatic S7-1500 CPU 1512C-1 PN Specifications

General

Integrated Interfaces	PROFINET
Data Memory	1 MB
Number of Signal Boards	1
Firmware Version	V2.8
Rated Value (DC)	24 V
Number of PROFINET Ports	2
Number of PROFINET Ports with Switch	2
Integrated Web Server	Yes
Number of Digital Inputs	16
Number of Digital Outputs	16
Number of Analog Outputs	2
Number of High-speed Counters	6
Program Memory	300 KB
Number of Signal Modules	32
Engineering with	STEP 7 Professional V13
Interface Type	Ethernet
Data Storage	Yes
Operating Temperature	0 to 60 °C
Dimensions	147 mm x 129 mm
