Siemens Simatic S7-1500 CPU 1512C-1 PN User Manual

Technical specifications
CPU 1512C-1 PN (6ES7512-1CK01-0AB0)
146 Manual, 12/2017, A5E40898741-AA
Article number
6ES7512-1CK01-0AB0
Input delay (for rated value of input voltage)
for standard inputs
– parameterizable
Yes; none / 0.05 / 0.1 / 0.4 / 1.6 / 3.2 / 12.8 / 20
ms
– at "0" to "1", min.
4 µs; for parameterization "none"
– at "0" to "1", max.
20 ms
– at "1" to "0", min.
4 µs; for parameterization "none"
– at "1" to "0", max.
20 ms
for interrupt inputs
– parameterizable
Yes; Same as for standard inputs
for counter/technological functions
– parameterizable
Yes; Same as for standard inputs
Cable length
• shielded, max.
1 000 m; 600 m for technological functions; de-
pending on input frequency, encoder and cable
quality; max. 50 m at 100 kHz
• unshielded, max.
600 m; For technological functions: No
Digital outputs
Type of digital output
Transistor
integrated channels (DO)
32
Current-sourcing
Yes; Push-pull output
Short-circuit protection
Yes; electronic/thermal
• Response threshold, typ.
1.6 A with standard output, 0.5 A with high-speed
output; see manual for details
Controlling a digital input
Yes
Accuracy of pulse duration Up to ±100 ppm ±2 μs at high-speed output; see
manual for details
minimum pulse duration
2 µs; With High Speed output
Digital output functions, parameterizable
• Switching tripped by comparison values
Yes; As output signal of a high-speed counter
• PWM output
Yes
– Number, max.
4
– Cycle duration, parameterizable
Yes
– ON period, min.
0 %
– ON period, max.
100 %
– Resolution of the duty cycle
0.0036 %; For S7 analog format, min. 40 ns
• Frequency output
Yes
• Pulse train
Yes; also for pulse/direction interface

Siemens Simatic S7-1500 CPU 1512C-1 PN Specifications

General

Integrated Interfaces	PROFINET
Data Memory	1 MB
Number of Signal Boards	1
Firmware Version	V2.8
Rated Value (DC)	24 V
Number of PROFINET Ports	2
Number of PROFINET Ports with Switch	2
Integrated Web Server	Yes
Number of Digital Inputs	16
Number of Digital Outputs	16
Number of Analog Outputs	2
Number of High-speed Counters	6
Program Memory	300 KB
Number of Signal Modules	32
Engineering with	STEP 7 Professional V13
Interface Type	Ethernet
Data Storage	Yes
Operating Temperature	0 to 60 °C
Dimensions	147 mm x 129 mm
