Technical specifications
CPU 1512C-1 PN (6ES7512-1CK01-0AB0)
Manual, 12/2017, A5E40898741-AA
147
Article number
6ES7512-1CK01-0AB0
Switching capacity of the outputs
• with resistive load, max.
0.5 A; 0.1 A with high-speed output, i.e. when
using a high-speed output; see manual for details
• on lamp load, max.
5 W; 1 W with high-speed output, i.e. when using
a high-speed output; see manual for details
Load resistance range
• lower limit
48 Ω; 240 ohms with high-speed output, i.e. when
using a high-speed output; see manual for details
• upper limit
12 kΩ
Output voltage
• Type of output voltage
DC
• for signal "0", max.
1 V; With high-speed output, i.e. when using a
high-speed output; see manual for details
• for signal "1", min.
23.2 V; L+ (-0.8 V)
Output current
• for signal "1" rated value
0.5 A; 0.1 A with high-speed output, i.e. when
using a high-speed output, observe derating; see
manual for details
• for signal "1" permissible range, min.
2 mA
• for signal "1" permissible range, max.
0.6 A; 0.12 A with high-speed output, i.e. when
using a high-speed output, observe derating; see
manual for details
• for signal "0" residual current, max.
0.5 mA
Output delay with resistive load
• "0" to "1", max.
200 µs
• "1" to "0", max.
500 µs; Load-dependent
for technological functions
– "0" to "1", max.
5 µs; Depending on the output used, see addi-
tional description in manual
– "1" to "0", max.
5 µs; Depending on the output used, see addi-
tional description in manual
Parallel switching of two outputs
• for logic links
Yes; For technological functions: No
• for uprating
No
• for redundant control of a load
Yes; For technological functions: No
Switching frequency
• with resistive load, max.
100 kHz; For high-speed output, 100 Hz for
standard output
• with inductive load, max.
0.5 Hz; Acc. to IEC 60947-5-1, DC-13; observe
derating curve
• on lamp load, max.
10 Hz
