Siemens Simatic S7-1500 CPU 1512C-1 PN User Manual

Parameter data records
B.2 Structure of a data record for input channels of the analog on-board I/O
CPU 1512C-1 PN (6ES7512-1CK01-0AB0)
Manual, 12/2017, A5E40898741-AA
171
Hardware interrupt limits
The values that can be set for hardware interrupts (high/low limit) must be within the nominal
range and overrange/underrange of the relevant measuring range.
The following tables list the permitted hardware interrupt limits. The limits depend on the
selected measurement type and measuring range.
Table B- 4 Voltage limits
Voltage
±5 V, ±10 V
1 to 5 V, 0 to 10 V
32510 32510 High limit
-32511
-4863
Low limit
Table B- 5 Current and resistance limits
Current
Resistance
±20 mA 4 to 20 mA /
0 to 20 mA
(all configurable measuring ranges)
32510
32510
32510
High limit
-32511
-4863
1
Low limit
Table B- 6 Limits for thermal resistor Pt 100 Standard and Pt 100 Climate
Thermal resistor
Pt 100 Standard
Pt 100 Climate
°C
°F
K
°C
°F
K
9999
18319
12731
15499
31099
---
High limit
-2429
-4053
303
-14499
-22899
---
Low limit
Table B- 7 Limits for thermal resistor Ni 100 Standard and Ni 100 Climate
Thermal resistor
Ni 100 Standard
Ni 100 Climate
°C
°F
K
°C
°F
K
2949
5629
5681
15499
31099
---
High limit
-1049
-1569
1683
-10499
-15699
---
Low limit

Siemens Simatic S7-1500 CPU 1512C-1 PN Specifications

General

Integrated Interfaces	PROFINET
Data Memory	1 MB
Number of Signal Boards	1
Firmware Version	V2.8
Rated Value (DC)	24 V
Number of PROFINET Ports	2
Number of PROFINET Ports with Switch	2
Integrated Web Server	Yes
Number of Digital Inputs	16
Number of Digital Outputs	16
Number of Analog Outputs	2
Number of High-speed Counters	6
Program Memory	300 KB
Number of Signal Modules	32
Engineering with	STEP 7 Professional V13
Interface Type	Ethernet
Data Storage	Yes
Operating Temperature	0 to 60 °C
Dimensions	147 mm x 129 mm
