Siemens Simatic S7-1500 CPU 1512C-1 PN User Manual

Parameter data records
B.2 Structure of a data record for input channels of the analog on-board I/O
CPU 1512C-1 PN (6ES7512-1CK01-0AB0)
170 Manual, 12/2017, A5E40898741-AA
Codes for temperature coefficient
The following table lists all temperature coefficients for temperature measurement of the
thermal resistors along with their codes. You must enter these codes in each case in byte 4
of the data record for the corresponding channel (refer to the figure Structure of data record
0: Bytes 0 to 6)
Table B- 3 Codes for temperature coefficient
Temperature coefficient
Code
Pt xxx
0.003851
0.003916
0.003902
0.003920
0000 0000
0000 0001
0000 0010
0000 0011
Ni xxx
0.006180
0.006720
0000 1000
0000 1001

Siemens Simatic S7-1500 CPU 1512C-1 PN Specifications

General

Integrated Interfaces	PROFINET
Data Memory	1 MB
Number of Signal Boards	1
Firmware Version	V2.8
Rated Value (DC)	24 V
Number of PROFINET Ports	2
Number of PROFINET Ports with Switch	2
Integrated Web Server	Yes
Number of Digital Inputs	16
Number of Digital Outputs	16
Number of Analog Outputs	2
Number of High-speed Counters	6
Program Memory	300 KB
Number of Signal Modules	32
Engineering with	STEP 7 Professional V13
Interface Type	Ethernet
Data Storage	Yes
Operating Temperature	0 to 60 °C
Dimensions	147 mm x 129 mm
