Parameter data records
B.3 Structure of a data record for output channels of the analog on-board I/O
CPU 1512C-1 PN (6ES7512-1CK01-0AB0)
174 Manual, 12/2017, A5E40898741-AA
Codes for output ranges
The following table contains all output ranges for voltage and current of the outputs of the
analog on-board I/O with the corresponding codes. You must enter these codes in each case
in byte 3 of the corresponding data record (see previous figure).
Table B- 9 Codes for output range
Output range for voltage
Code
1 to 5 V
0 to 10 V
±10 V
0000 0011
0000 0010
0000 0000
Output range for current
Code
0 to 20 mA
4 to 20 mA
±20 mA
0000 0001
0000 0010
0000 0000
Permitted substitute values
The following table lists all output ranges for the permitted substitute values. You must enter
these substitute values in each case in bytes 6 and 7 of the data record for the
corresponding channel (see the previous figure). You can find the binary representation of
the output ranges in the section Representation of output ranges (Page 203).
Table B- 10 Permitted substitute value for the output range
Output range
Permitted substitute value
±10 V
1 to 5 V
0 to 10 V
-32512 ... +32511
-6912 ... +32511
0 ... +32511
±20 mA
4 to 20 mA
0 to 20 mA
-32512 ... +32511
-6912 ... +32511
0 ... +32511

Siemens Simatic S7-1500 CPU 1512C-1 PN Specifications

General

Integrated Interfaces	PROFINET
Data Memory	1 MB
Number of Signal Boards	1
Firmware Version	V2.8
Rated Value (DC)	24 V
Number of PROFINET Ports	2
Number of PROFINET Ports with Switch	2
Integrated Web Server	Yes
Number of Digital Inputs	16
Number of Digital Outputs	16
Number of Analog Outputs	2
Number of High-speed Counters	6
Program Memory	300 KB
Number of Signal Modules	32
Engineering with	STEP 7 Professional V13
Interface Type	Ethernet
Data Storage	Yes
Operating Temperature	0 to 60 °C
Dimensions	147 mm x 129 mm
