Technology functions
3.2 Pulse generators
CPU 1512C-1 PN (6ES7512-1CK01-0AB0)
Manual, 12/2017, A5E40898741-AA
61
Diagnostics
interrupt
No supply voltage
L+
The parameter "No supply voltage
L+" activates the diagnostic inter-
rupt of the channel in the case of
Deactivated
Parameter High-speed output
(0.1 A)
The "High-speed output (0.1 A)"
parameter is used to specify
whether you want to use the se-
lected pulse output as high-speed
output. Requirement for this is that
the selected pulse output supports
the operation as high-speed out-
put.
The output supports frequencies
of up to 10 kHz (load dependent)
and currents of up to 0.5 A or
frequencies of up to 100 Hz and
currents of up to 0.5 A depending
on the performance capability of
Deactivated
The output supports frequencies
of up to 100 kHz and currents of
Output format Defines the value for the frequen-
cy output in the field
"OUTPUT_VALUE" of the control
duration of the channel.
Interprets the value of the fre-
quency output in the field
"OUTPUT_VALUE" as frequency
1 Hz
Hardware
inputs /
outputs
Pulse output
(DQA)
The parameter "Pulse output
(DQA)" is used to define the hard-
ware output that you want to use
as pulse output channel.
For B:
X11, terminal 21 (DQ0 / %Q4.0):
10 kHz / 0.5 A or 100 kHz / 0.1 A
Hardware
output for the
least signifi-
cant address
For B:
X11, terminal 31 (DQ8 / %Q5.0):
Output signals for frequency output mode
Continuous pulse current at the digital
A pulse for the assigned frequency is output
at the digital output PWM DQA.
Continuous pulse current
