Technology functions
3.2 Pulse generators
CPU 1512C-1 PN (6ES7512-1CK01-0AB0)
Manual, 12/2017, A5E40898741-AA
65
Increments per revolu-
tion
The "Increments per
revolution" is used to
define the number of
increments per revolu-
tion (also in microstep
mode), which is re-
quired by the drive for a
1 to 1,000,000 200
Fine resolution Bits in incr. actual value
(G1_XIST1)
The parameter defines
the number of bits for
the coding of the fine
resolution in the current
incremental value of
0 0
Stop behavior Quick stop time The parameter "Quick
stop time" defines the
time interval it should
take for the drive to go
from the maximum
speed to a standstill
(OFF3).
1 to 65 535 (ms) 1,000 (ms)
Hardware
inputs /
outputs
Reference switch input The parameter "Refer-
ence switch input"
defines the hardware
input of the reference
[Input address of the reference
switch DI]
--
Edge selection refer-
ence switch
The parameter "Edge
selection reference
switch" defines the
edge type which is to
be detected by the
Rising edge
Falling edge
Measuring input The parameter "Meas-
uring input" defines the
hardware input of the
[Input address of the measuring
input DI]
--
"Drive ready" input The parameter ""Drive
ready" input" defines
the hardware input of
[Input addresses of the inputs
"Drive ready" DIn]
--
Pulse output A
for "PTO (pulse (A) and
direction (B))"
The parameter "Pulse
output A" defines the
hardware output for
PTO signal A.
[Output address DQ for PTO
signal A (output frequency
100 kHz)]
grayed out
Read only ac-
cess to the pa-
Direction output B
for "PTO (pulse (A) and
direction B))"
The parameter "Direc-
tion output B" defines
the hardware output for
PTO signal B.
[Output address 1 of the DQ for
PTO signal B (output frequency
Qn (output fre-
quency 100 kHz)
[Output address 2 of the DQ for
PTO signal B (output frequen-
