1.1 Possible applications for the CP 341
CP 341 Point-to-Point Communication, Installation and Parameter Assignment
18 Manual, 09/2008, A5E02191071-01
Functions of module variants
Different driver functions can be used depending on the module variant of the CP 341:
Table 1- 2 Functions of CP 341 module variants
Function CP 341-
RS 232C
CP 341-
20mA-TTY
CP 341-RS 422/485
RS 422* RS 485*
ASCII driver: Yes Yes Yes Yes
Control of RS 232C accompanying signals Yes No No No
Controlling/reading of RS 232C
accompanying signals with FBs
Yes No No No
RTS/CTS flow control Yes No No No
XON/XOFF flow control Yes Yes Yes No
3964(R) procedure Yes Yes Yes No
RK 512 computer link Yes Yes Yes No
Printer driver Yes Yes Yes Yes
* The RS 422 and RS 485 are differentiated through parameter assignment.
Uses of the CP 341
The CP 341 communication processor enables a point-to-point connection with various
Siemens modules and with non-Siemens products:
● SIMATIC S5 via the 3964(R) driver or RK 512 with corresponding interface module on S5
side
● Siemens PDA terminals from the ES 2 family via 3964(R) driver
● MOBY I (ASM 420/421, SIM), MOBY L (ASM 520) and ES 030K data acquisition terminal
via 3964R driver
● PCs via the 3964(R) procedure (the following development tools are available for
programming on PCs: PRODAVE DOS 64R (6ES5 897–2UD11) for MS-DOS,
PRODAVE WIN 64R
(6ES5 897-2VD01) for Windows or the ASCII driver)
● Barcode readers via the 3964(R) or ASCII driver
● Non-Siemens PLCs via the 3964(R) driver, ASCII driver, or RK 512
● Other devices with simple protocol structures by means of appropriate protocol
adaptation with the ASCII driver
● Other devices that also have a 3964(R) driver or RK 512
● Printers (HP Deskjet, HP Laserjet, Postscript, Epson, IBM)
The CP 341 can also be operated in a distributed configuration using the ET 200M (IM153)
I/O device.
