Basic Principles of Serial Data Transmission
2.8 Configuration data
CP 341 Point-to-Point Communication, Installation and Parameter Assignment
Manual, 09/2008, A5E02191071-01 97
Character set
The table below contains a description of the parameters for the character set.
Table 2- 20 Character set (printer driver)
Parameters Description Range of values Default value
Printer character set Set "IBM" to convert the set Windows ANSI character
set into the printer character set. If you set "User-
Defined", you can adapt the character set to include
special characters for a particular language.
• IBM
• User-defined
IBM
Control characters
The table below contains a description of the parameters for control characters.
Table 2- 21 Control characters (printer driver)
Parameters Description Range of values Default value
Printer emulation Sets the printer emulation (printer commands for the
following control characters: bold, condensed, expanded,
italics, and underlining). Set "User-Defined" to modify the
printer emulation and include additional control characters.
The characters A to Z and a to z are permissible as control
characters.
• HP DeskJet
• HP LaserJet
• IBM Proprinter
• User-defined
HP DeskJet
Performance features
Boundary conditions for configuring message texts:
● Size of the text SDB: 15 kbytes
● Max. length of a message text without variables: 150 characters
● Maximum length of message texts with variables displayed: 250 characters
● Maximum number of variables per message text: 4 (3 + message text number)
