Siemens SIMATIC S7-300 Module data Product Information

Commissioning
3.2 Connecting hardware components
Connection of the SINAMICS S120 to the Technology CPU
Product Information, 09/2011, A5E00480378-04
19
Recommended DRIVE-CLiQ rules
When the recommended rules for DRIVE-CLiQ wiring are observed, the components will be
automatically assigned to the drives during online configuration or during topology
recognition.
Note
Complete, detailed information about these rules is contained in the documentation for the
SINAMICS S120 drive system available on the Internet
(http://apps01.industry.siemens.com/c
ontent/00000100/Content/syn_s120.aspx?rc=1).
Examples
Sample interconnection with an Active Line Module:
&8
;
;
;
;
;
;
;
;
;
;
;
;





;
;
;
$FWLYH/LQH
0RGXOH
'RXEOH0RWRU
0RGXOH
6LQJOH0RWRU
0RGXOH
0RWRU
(QFRGHU
0RWRU
(QFRGHU
0RWRU
(QFRGHU

Siemens SIMATIC S7-300 Module data Specifications

General

Series	S7-300
Manufacturer	Siemens
Protection Class	IP20
System	SIMATIC S7-300
Digital Inputs	Varies by module
Digital Outputs	Varies by module
Analog Inputs	Varies by module
Analog Outputs	Varies by module
Central Processing Unit	Varies by CPU model
Supply Voltage	24V DC or 120/230V AC
CPU Type	Varies (e.g., CPU 312, CPU 315, etc.)
Memory	Varies by CPU model
Communication Interfaces	MPI, PROFIBUS
Programming Languages	LAD, FBD, STL, SCL, GRAPH
Operating Temperature	0°C to 60°C
Storage Temperature	-40°C to 70°C
Relative Humidity	10% to 95% (non-condensing)
