Networking
5-30
S7-400 and M7-400 Programmable Controllers, Installation Manual
C79000-G7076-C424-01
Sender
Receiver
Fiber-optic
cables
Connector adapter
Simplex
connectors
Figure 5-4 Simplex connectors and a special connector adapter for the IM 153-2 FO and
IM 467 FO (installed)
Order numbers
You can order Simplex connectors and connector adapters as follows:
Table 5-6 Order numbers – Simplex connectors and connector adapters
Accessories
Order number
SIMATIC NET PROFIBUS plastic fiber-optic Simplex
connector/polishing set
100 Simplex connectors and 5 polishing sets for fitting
SIMATIC NET PROFIBUS plastic fiber-optic cables
with connectors
6GK1901–0FB00–0AA0
Connector adapters
Pack of 50 for fitting plastic Simplex connectors with
the IM 467 FO and the IM 153-2 FO
6ES7195–1BE00–0XA0
