Assembling the M7-400
8-7
S7-400 and M7-400 Programmable Controllers, Installation Manual
C79000-G7076-C424-01
8.4 Installing the M7-400
Introduction
This section contains the important information you need for installing the M7-400.
You will learn:
The sequence for installation from a checklist
Which module accessories were already provided and which ones you can
order as options
How to install the DRAM memory cards of the main memory in the CPU
How to insert an interface submodule in a CPU or expansion module
How to insert a short AT card in an AT adapter module
How to fit expansion modules on a CPU
How to install a module assembly in a rack
All other important information for installation applies both to S7-400 and M7-400
modules and is described in Chapter 5.
