Installing the S7-400
2-34
S7-400 and M7-400 Programmable Controllers, Installation Manual
C79000-G7076-C424-01
2.15 Accessories
Accessories
Some of the accessories needed for fitting the modules in the rack are provided in
the packaging of the modules and racks. The front connectors of the signal
modules must always be ordered separately. There are also optional accessories
for some modules.
The accessories for modules and racks are listed and briefly explained in
Table 2-2. A list of spare parts for SIMATIC S7 can be found in the
Reference
Manual
, Chapter 11. The accessories for installing the M7-400 can be found in
Section 8.4.
Table 2-2 Accessories for Modules and Racks
Module
Accessories
Supplied
Accessories Not
Supplied
Purpose of the Accessory
Rack (UR, CR, ER) Number wheel with
slot labels
- For identifying the modules with
slot labels
Power Supply
Module (PS)
- 1 or 2 backup batteries For central backup of RAM areas
in the CPU
CPU 2 keys - To operate the mode selector of
the CPU
- Memory cards Load memories required for the
CPU
Signal Module
(SM)
2 labels
Plate with pinout
-
-
For labeling the inputs and
outputs on the front connector
To identify the pinout of the front
connectors
- Front connector with
strain relief for screw,
crimp or spring-type
terminal
For wiring the SMs
-
-
-
Extraction tool (for
crimp terminals)
Crimp contacts
Crimping tool
For rewiring SMs with a front
connector with crimp terminals
