Networking
5-29
S7-400 and M7-400 Programmable Controllers, Installation Manual
C79000-G7076-C424-01
Table 5-5 Order numbers – fiber-optic cables, continued
Fiber-optic cables Order numberForm
SIMATIC NET PROFIBUS plastic fiber-optic, standard cable
I–VY4Y2P 980/1000 160A
Robust round cable with 2 plastic fiber-optic cable conductors,
PVC outer sheath and PA inner sheath, without connectors,
for use indoors
per meter
50 m ring
100 m ring
6XV1821–0AH10
6XV1821–0AN50
6XV1821–0AT10
SIMATIC NET PROFIBUS PCF fiber-optic, standard cable
I–VY2K 200/230 10A17 + 8B20
PCF fiber-optic cable with 2 conductors, PVC outer sheath, fitted
with 4 Simplex connectors, whip length 30 cm each, for distances
up to 300 m
(Other lengths on request)
50 m
75 m
100 m
150 m
200 m
250 m
300 m
6XV1821–1CN50
6XV1821–1CN75
6XV1821–1CT10
6XV1821–1CT15
6XV1821–1CT20
6XV1821–1CT25
6XV1821–1CT30
5.8.2 Simplex connectors and connector adapter
Definition
Simplex connectors allow you to connect the fiber-optic cable to the integrated
fiber-optic cable interface on the PROFIBUS device. In some Siemens modules
(e.g. IM 153-2 FO, IM 467 FO) two Simplex connectors (one for the sender and
one for the receiver) are inserted in the module by means of a special connector
adapter.
Prerequisite
The PROFIBUS device must be equipped with a fiber-optic cable interface, such
as the ET 200M (IM153-2 FO) or the IM 467 FO for S7-400.
Structure
Two Simplex connectors (a sender and a receiver) and a connector adapter with
the following attributes are required for a fiber-optic cable connection:
IP 20 protection
Transmission rates of 9.6 kbps to 12 Mbps
