Assembling the M7-400
8-48
S7-400 and M7-400 Programmable Controllers, Installation Manual
C79000-G7076-C424-01
EXM 478
Frame of card slot with
mounting hole
Guides
Figure 8-21 Removing an Interface Submodule from the Card Slot of an Expansion
Module
Fitting an Interface Submodule
Fit the new interface submodule in the reverse order. Further information can be
found in Section 8.4.4, “Installing Interface Submodules” from page 8-12.
