Preface
v
S7-400 and M7-400 Programmable Controllers, Installation Manual
C79000-G7076-C424-01
Additional Manuals Required for S7-400
This documentation package describes the hardware of the S7-400. You will need
the following additional documentation for programming and starting up an S7-400:
Manual/
Manual Package
Contents
Standard Software
for S7 and M7
STEP 7 Basic
Information
 Installing and starting up STEP 7 on a programming device / PC
 Working with STEP 7 with the following contents:
Managing projects and files
Configuring and assigning parameters to the S7-400 configuration
Assigning symbolic names for user programs
Creating and testing a user program in STL/LAD
Creating data blocks
Configuring the communication between two or more CPUs
Loading, storing and deleting user programs in the CPU / programming device
Monitoring and controlling user programs
Monitoring and controlling the CPU
 Guide for efficiently implementing the programming task with the programming
device / PC and STEP 7
 How the CPUs work (for example, memory concept, access to inputs and
outputs, addressing, blocks, data management)
 Description of STEP 7 data management
 Using data types of STEP 7
 Using linear and structured programming
 Using block call instructions
 Using the debug and diagnostic functions of the CPUs in the user program (for
example, error OBs, status word)
STEP 7 Reference
Information
Statement List (STL)
for S7-300 and
S7-400
Ladder Logic (LAD)
for S7-300 and
 Basic procedure for working with STL, LAD, or FBD (for example, structure of
STL, LAD, or FBD, number formats, syntax)
 Description of all instructions in STEP 7 (with program examples)
 Description of the various addressing methods in STEP 7 (with examples)
 Description of all functions integrated in the CPUs
 Description of the internal registers in the CPU
f
or
S7
-
300
an
d
S7-400
Function Block
Diagram (FBD) for
S7-300 and S7-400
System and
Standard Functions
Descri tion
of
the
internal
registers
in
the
CPU
 Description of all system functions integrated in the CPUs
 Description of all organization blocks integrated in the CPUs
Manual
PG 7xx
 Description of the programming device hardware
 Connecting a programming device to various devices
 Starting up a programming device
