1.2.2 Required Software Components
Software components
The following table lists the software components required for establishing a point-to-point
connection with the CP 440.
Table 1-3 Software Components for a Point-to-Point Connection with the CP 440
Components Function Diagram
STEP 7 software package ... congures, assigns parameters, pro‐
grams and tests the S7-400.
Parameter assignment interface: Point-to-
Point Communication, Parameter As‐
signment interface, Version 5.1
... assigns parameters for the interfaces of
the CP 440.
Function blocks (FBs) with programming
examples
... controls the communication between
CPU and CP 440.
1.2.3 Incompatible CPU versions
CPU versions
The CP 440 can be operated with all CPU versions except the CPUs listed in the tables below:
Table 1-4 CPU Versions with Which the CP 440 Can Be Used as of the Version Indicated
CPU Order number
CPU 412-1 6ES7 412-1XF01-0AB0, Release 5
CPU 413-1 6ES7 413-1XG01-0AB0, Release 5
CPU 413-2 6ES7 413-2XG01-0AB0, Release 5
CPU 414-1 6ES7 414-1XG01-0AB0, Release 5
CPU 414-2 with 128k 6ES7 414-2XG01-0AB0, Release 5
CPU 414-2 with 348k 6ES7 414-2XJ00-0AB0, Release 7
CPU 416-1 6ES7 416-1XJ01-0AB0, Release 5
CPU 416-2 with 0.8 M 6ES7 416-2XK00-0AB0, Release 7
CPU 416-2 with 1.6 M 6ES7 416-2XL00-0AB0, Release 7
CPU 416-2 DP ISA Lite
CPU 416-2 DP ISA
CPU 412-2 DP PCI
CPU 416-2 DP PCI
6ES7 616-2PK00-0AB4, Release 3
Product Description
1.2 Components Required for a Point-to-Point Connection with the CP 440
Point-to-point connection CP 440 Installation and Parameter Assignment
Equipment Manual, 03/2022, A5E00057742-AE 13
