Assignment in the data area
The RES_RECV FB works with an instance DB (I_RES_RECV). The DB number is specied in the call.
The data in the instance DB cannot be accessed.
Note
Exception: If the error STATUS == W#16#1E0F occurs, you can consult the SFCERR variable for
more details of the error. This error variable can only be loaded via a symbolic access to the
instance DB.
Parameters of the RES_RECV FB
The following table lists the parameters of the RES_RECV FB.
Table 6-4 Parameters of the RES_RECV FB
Name Type Data type Description Permitted Values, Comment
REQ INPUT BOOL Initiates request with posi‐
tive edge
R INPUT BOOL Aborts request Current request is aborted. Sending is blocked.
LADDR INPUT INT Basic address of CP 440 The basic address is taken from STEP 7.
DONE
1
OUTPUT BOOL Request completed without
errors
STATUS parameter == 16#00;
ERROR
1
OUTPUT BOOL Request completed with er‐
rors
STATUS parameter contains error details
STATUS
1
OUTPUT WORD Error specication If ERROR == 1, STATUS parameter contains error
details
1
The parameter is available until the next call of the FB!
Communication via Function Blocks
6.3 Using the Function Blocks
Point-to-point connection CP 440 Installation and Parameter Assignment
84 Equipment Manual, 03/2022, A5E00057742-AE
