Siemens SIMATIC S7-GRAPH User Manual

Overview of All Actions
S7-GRAPH for S7-300/400 Programming Sequential Control Systems
C79000-G7076-C526-01
13-11
Action Explanation Address
range
Event Instruction Address
Area
Location
A1 NC Q,I,M,D* m.n As soon as a message is
acknowledged and the
condition (interlock) is
satisfied, the address has
signal state 1.
0.0 to
65535.7
A1 SC Q,I,M,D* m.n As soon as a message is
acknowledged and the
condition (interlock) is
satisfied, the address is set to
1 and then remains set to 1.
0.0 to
65535.7
A1 RC Q,I,M,D* m.n As soon as a message is
acknowledged and the
condition (interlock) is
satisfied, the address is set to
0 and then remains set to 0.
0.0 to
65535.7
A1 CALLC FB, FC,
SFB, SFC
Block
number
As soon as a message is
acknowledged and the
condition (interlock) is
satisfied, the specified block
is called.
A1 ONC S i As soon as a message is
acknowledged and the
condition (interlock) is
satisfied, step i is activated.
i = step
number
A1 OFFC S i As soon as a message is
acknowledged and the
condition (interlock) is
satisfied, step i is deactivated.
i = step
number
R1: Actions linked to setting a registration
R1 N Q,I,M,D* m.n As soon as a registration is
set, the address has signal
state = 1.
0.0 to
65535.7
R1 S Q,I,M,D* m.n As soon as a registration is
set, the address is set to 1
and then remains set to 1.
0.0 to
65535.7
R1 R Q,I,M,D* m.n As soon as a registration is
set, the address is set to 0
and then remains set to 0.
0.0 to
65535.7
R1 CALL FB, FC,
SFB, SFC
Block
number
As soon as a registration is
set, the specified block is
called.
